SPR-RP700 Planer Sanding Machine
Product Overview
The SPR-RP700 planer sanding machine is designed for high-precision calibration and fine surface sanding of solid wood, veneer boards, and furniture components. It delivers superior sanding uniformity and surface flatness in a compact, efficient structure—making it ideal for small to medium-sized furniture and panel factories.
Key Features
-
Compact & Efficient Design – 700 mm working width fits most furniture and component production lines.
-
Dual Sanding Belts – Enables rough and fine sanding in one pass for consistent quality.
-
High-Speed Cutter Head – Ensures smooth calibration with excellent surface accuracy.
-
Variable Feed Speed – Adjustable from 6 – 30 m/min to suit different materials.
-
Low Noise & Stable Operation – Heavy-duty steel frame minimizes vibration.
-
Optimized Dust Extraction – Eight dust ports (φ120 × 8) keep the working environment clean.
| Parameter | Specification |
|---|---|
| Working width | 40 – 700 mm |
| Working thickness | 10 – 160 mm |
| Minimum workpiece length | ≥ 500 mm |
| Cutter roller speed | 28 m/s |
| 1st sanding belt speed | 21 m/s |
| 2nd sanding belt speed | 16 m/s |
| Feed speed | 6 – 30 m/min |
| Sanding belt size | 730 × 2100 mm |
| Total motor power | 41.2 kW |
| Cutter motor | 15 kW |
| 1st sanding belt motor | 15 kW |
| 2nd sanding belt motor | 7.5 kW |
| Feed motor | 3 kW |
| Brush motor | 0.37 kW |
| Table lift motor | 0.37 kW |
| Dust outlet diameter | φ120 × 8 |
| Air pressure | 0.6 MPa |
| Air consumption | 0.2 m³/min |
| Required air volume | 8000 m³/h |
| Average suction speed | 25 – 30 m/s |
| Overall dimensions | 244 × 136 × 206 cm |
| Net weight | 3000 kg |
Applications
Ideal for:
-
Solid wood furniture parts
-
Veneer boards and MDF panels
-
Door panels and flooring components
-
Pre-coating surface sanding
