Highlights
The NPC330S Panel Dividing Saw is designed for high-speed batch sizing of furniture panels and wood-based boards. Compared with conventional pressure-beam systems, the NPC330S uses servo-controlled lifting for fast and precise positioning according to cutting thickness, while clamping pressure automatically adjusts based on panel width and material. The saw blade lifting height is also servo controlled, allowing grooving at selectable depths with ±0.1 mm precision. Integrated production software supports cutting-pattern simulation, process reports, fault display and barcode printing for organized panel production.
- Maximum cutting length: 3300 mm
- Maximum cutting thickness: 90 mm
- Main saw motor: 15 kW
- Saw carriage speed: 100 m/min forward / 120 m/min return
- Automatic feeding speed: 85 m/min
- Grooving precision: ±0.1 mm
- Total power: 21.5 kW
Video
3D Images
NPC330 – 3D model by nanxing_ru (@nanxing_ru) [c8cc68a]
Features
- Servo-controlled pressure beam lifting provides fast and precise height positioning.
- Clamping pressure automatically adjusts according to workpiece width and material.
- Servo-controlled saw blade lifting supports variable-depth grooving with ±0.1 mm precision.
- Quick-change main saw blade design helps reduce maintenance and blade replacement time.
- Production software supports cutting simulation, barcode printing, reports and fault diagnostics.
Technical data
| Specifications | Unit | NPC330S |
|---|---|---|
| Maximum cutting length | mm | 3300 |
| Maximum cutting thickness | mm | 90 |
| Main saw motor power | kW | 15 |
| Main saw speed | r/min | 3910 |
| Main saw blade diameter | mm | Ø380, max. Ø400 |
| Main saw shaft diameter | mm | Ø60 |
| Scoring saw motor | kW | 2.2 |
| Scoring saw speed | r/min | 4300 |
| Saw carriage motor | kW | 2 |
| Saw carriage forward speed | m/min | 100 |
| Saw carriage return speed | m/min | 120 |
| Automatic feeding motor | kW | 2 |
| Main gripper speed | m/min | 85 |
| Gripper quantity | pcs | 10 |
| Blower power | kW | 2 |
| Air pressure | MPa | 0.6 |
| Dust extraction ports | mm | Ø150 × 3 |
| Required extraction air velocity | m/min | 28 |
| Power supply | — | AC 3P 380 V / 50 Hz |
| Total power | kW | 21.5 |
| Overall dimensions | mm | 6900 × 5495 × 1830 |
| Net weight | kg | 5500 |
