Low-Profile Hydraulic Scissor Lift Table

Highlights

The Low-Profile Hydraulic Scissor Lift Table is designed for heavy panel, pallet and stacked-material handling where a low loading height is required. Its ultra-low platform design allows floor-level installation without a foundation pit, making it suitable for existing factories and space-restricted production areas. The system combines a hydraulic scissor structure with a powered roller platform for easier integration with conveyors, loading systems and automated production lines. The standard configuration supports up to 3000 kg static load and 2000 kg dynamic load, while platform size, lifting stroke and load capacity can be customized according to project requirements.

• Minimum platform height: As low as 180 mm
• Static load capacity: Up to 3000 kg
• Dynamic load capacity: Up to 2000 kg
• Standard platform size: 2500 × 1200 mm
• Hydraulic power: 3 kW
• Installation: Pit-free / Floor mounted
• Configuration: Customizable

Images

Features

• Ultra-low platform design allows direct floor installation without excavation or a foundation pit.
• Powered roller platform supports direct material transfer between conveyors and loading stations.
• One-piece platform and heavy-duty scissor structure improve stability when handling stacked panels and pallets.
• Suitable for furniture factories, panel warehouses and automated material-handling lines.
• Platform dimensions, lifting height and load capacity can be customized according to production requirements.
